Megger OTS80AF/2 - Product View

5
Cradle terminal
T
est chamber
Sheet steel case
Carrying handle
Control panel
Internal printer
H.V. transformer
output terminal
‘
horns’
E.M.C./ Discharge
barrier
Oil test vessel
Hinged
polycarbonate
cover
Safety
interlock on test
chamber
H.V. indicator
Printer paper
feed key
Liquid crystal
display
Control
keys
Power supply
On/Off switch
External printer
connector
Mains
supply
socket
Fuses
Mains supply
voltage selector
Earth terminal
(additional)
Figure 2. Oil test set controls etc.
Figure 1. OTS100AF/2 oil test set layout (the OTS80AF/2 and OTS60AF/2 are similar).
Figure 3. Oil test set rear panel.
