Megger OTS80PB Quick Reference Guide

G SAFETY WARNINGS
Safety warnings and precautions must be read and under-
stood before the OTS80PB/OTS60PB is used. They must
be observed during use.
n The OTS80PB/OTS60PB must only be used in the way
intended and for the stated purposes described by
Megger.
n The OTS80PB/OTS60PB must not be used if any part
of it is damaged.
n The OTS80PB/OTS60PB must be properly earthed. A
supplementary earth terminal is provided.
n Position the OTS80PB/OTS60PB so that power can be
easily removed.
n The OTS80PB/OTS60PB must not be used in wet
locations or with rain falling on the instrument.
n The OTS80PB/OTS60PB must only be used for testing
electrical grades of insulating liquids. No other objects
or substances should be placed in the test chamber.
n The OTS80PB/OTS60PB must only be used with one
of Megger’s precision test vessels or VCM100D
correctly fitted on the support horns in the test
chamber.
n Replacement fuses must be of the correct type and
rating.
n If batteries are fitted, the 12 VDC charger must only
be powered from a negative earthed vehicle 12 VDC
source using the Megger supplied lead.
n Calibration or repair must only be carried out by a
Megger qualified repair facility.
n The test chamber must be kept clean and free from lint
or other fibres.
n The OTS80PB/OTS60PB weighs between 16 kg and
23 kg. Care should be taken when lifting the
instrument.
n It is prohibited to insert foreign objects into any gap on
the instrument before or during a test.
n Unit must be used in a well ventilated location. Small
quantities of Ozone may be created after prolonged
testing.
Symbols used on this instrument
G Caution: refer to accompanying notes
F Danger high voltage, risk of electrical shock
DC voltage
a AC voltage
c Equipment complies with current EU
Directives
u Earth terminal
f
Fuse
USB terminal
Equipment complies with ‘C tick’
requirements
Do not dispose of in the waste stream
Instrument setup
The OTS80PB/OTS60PB must only be used by suitably
trained persons.
Out of the box
List of items
n OTS80PB/OTS60PB Oil test set instrument
n 400 ml precision vessel assembly
n Electrode set(s) as ordered & feeler gauge set
n Impeller stirrer lid assembly if ordered
n Magnetic bead stirrers (2) and retriever
n User manual CD
n Power lead as ordered
n Carry case with shoulder strap if ordered
Accessories (supplied separately)
n Vessel assembly 150 ml
n Transportation case
n VCM100D voltage meter

Megger OTS80PB Specifications

General

Brand	Megger
Model	OTS80PB
Category	Test Equipment
Language	English
