Power cord test (PAT120, 150)
Testing a standard power cord
i) ii) iii) iv)
Insulation test @ 500 V
OR
Insulation test @ 250 V
>2 s
v) vi)
NOTE : For power cords longer than 5m the test can be re-run with a 1.0W pass limit by pressing the test button with 5 seconds of the continuity test failing – refer to page 13
