10. Battery indicator
The battery symbol on the LCD display contains four pairs of segments. The battery is monitored continuously when
the instrument is turned on. The charge remaining in the battery is indicated by segment pairs as follows:
Fully charged battery
50% charged battery
Tests cannot be started, insufficient charge
Symbol flashes when there is not enough charge
for a test and the instrument will turn itself off.
When mains power is present the indicator shows the battery is being charged by animating the segments of the bar
graph.
A blinking full battery icon indicates that the battery is prevented from charging due to the temperature being out of
the allowable charge temperature range, 0 ºC to 40 ºC, or that the battery has failed.
