14 VIDAR ZP-BR01E BR0150GE
6 SPECIFICATIONS
6
Specifications
Specifications VIDAR
Specifications are valid at nominal input voltage and an ambi-
ent temperature of +25°C, (77°F). Specifications are subject to
change without notice.
Environment
Application field The instrument is intended for use in
medium and high-voltage substations
and industrial environments.
Temperature
Operating -10°C to +50°C (14°F to +122°F)
Storage & transport -40°C to +70°C (-40°F to +158°F)
Humidity 5% – 95% RH, non-condensing
CE-marking
LVD 2006/95/EC
EMC 2004/108/EC
General
Mains voltage 115 / 230 V AC (switchable), 50 / 60 Hz
Power consumption 69 VA (max)
Protection Overload cut-out
Dimensions
Instrument 250 x 210 x 125 mm
(9.8” x 8.3” x 4.9”)
Transport case 460 x 430 x 210 mm
(18.0” x 17” x 8.3”)
Weight 6.9 kg (15.5 lbs)
10.7 kg (23.6 lbs) with accessories and
transport case
Measurement section
Indicators
Green lamp Indicates an approved breaking chamber
Red lamp Indicates a defect breaking chamber,
lights up if the current exceeds 0.3 mA
Yellow lamp Indicate that the test was interrupted
Output
Standard voltages,
switchable
10, 14, 25, 40 and 60 kV DC
Customized voltage Between 10 and 60 kV DC. Determined
at the factory. Default voltage is 50 kV.
Accuracy 0 to -15%
Ripple Max 3%
