General LED Light Codes
On - CF7000 OK.
Cycles x 5 - Normal power up sequence.
CF7000 OK.
Blinks Off - Coin accepted / rejected.
Flashing - CF7000 in Menu mode
On – CF7000 inhibited by VMC.
Flashing - CF7000 requires attention.
(Refer to Amber LED light codes)
Off - No Power to CF7000.
(Check power looms are connected & ensure
power is switched ON)
Alternating - CF7000 Faulty
(Remove from vending machine)
Amber LED Light Codes
If the amber LED flashes, this indicates that a fault has been detected on one of
the CF7000 main modules. These types of fault can be rectified at the machine
and can be for example caused by; a coin jam; dirt built up; or the cassette has
been removed etc. The CF7000 will also indicate the module affected on its
display.
Flashes Check CF7000 Module
1 x Discriminator
2 x Accept gate
3 x Separator module
4 x Dispenser module
