38
Content
1. General notes about this installation guide 39
2. Use and function 40
3. Scope of supply 41
4. General description 42
5. Assembly/installation 43
5.1 Preparatory work 44
5.2 Installing the meter 44
5.3 Fitting location and calming section 45
5.4 Fitting the temperature sensors 45
5.5 Completing work 47
6. Communication interfaces 48
6.1 Pin assignments 48
6.2 M-Bus 48
6.3 Pulse outputs 49
6.4 Optical interface 50
6.5 Wireless meter 51
7. Display options 52
7.1 Loop overview 52
7.2 Main loop 53
7.3 Service loop 54
7.4 Diagnostic display 55
8. Fault 57
8.1 Check meter 57
8.2 Troubleshooting 57
9. Technical data 59
9.1 Calculator 59
9.2 Display 59
9.3 Volume measurement 59
9.4 Temperature measurement 60
9.5 Voltage supply 60
9.6 Radio/Wireless 60
9.7 Volume/energy impulse open collector 61
9.8 General 61
10. Transport and storage 62
11. Name plate 63
12. Environmental note & Declarations of Conformity 64
