meibes Rossweiner Logoplus User Manual

61
9. Technical data
9.7 Volume⁄energy impulse open collector
Designation Value
Max. pulse frequency 4 Hz
Max. input voltage 30 VDC
Max. input current 27 mA
Max. voltage drop at the
active output
2 V/27 mA
Max. current through
inactive output
5 V/30 μA
Max. reversed voltage without
destruction of the outputs
6 V
Min. pulse duration 125 ms
Min. pulse interval 125 ms
9.8 General
Designation Value
Limits for temporary
ambient temperature
(operating)
0 °C … 55 °C
Limits for temporary
ambient temperature
(storage)
-20 °C … 55 °C
Rated pressure 16 bar
GB
