54
7. Display options
4. Continue by pressing button < 3 seconds.
Energy value (second mentioned energy value) on the reading date (for meters
with heat and cold memories).
The display changes between "second mentioned energy value" (3 seconds) and
"reading date" (for 1 second) for a total duration of 5 minutes. If the first reading
date has not yet been reached, the production date is shown.
7.3 Service loop
1. Switch to service loop by pressing button > 3 seconds.
Info: An S is shown at the bottom left of the display to indicate the service loop is active.
Actual flow in m³/h *1
2. Advance in the service loop by pressing button < 3 seconds.
Flow temp., always in °C to 1 decimal place
Return temp., always in °C to 1 decimal place
Temp. difference, always in °C to 1 decimal place (for meters with heat and cold
memories with signs)
Current power (always in kW, even if the base display is for example in MWh) *1
