Flicker quickly (125ms On/125ms Off)
Users can design schematic diagram using sink current, the reference circuit is as follows:
Figure 11 Reference Circuit of Network Indication
GPIO controlled can also be used, the other reference circuit is shown as follows:
Figure 12 Reference Circuit of Network Indication
3.13 Status Indicaiton
STATUS pin is used to indicate the working state of the module, when the module is turned on normally,
STATUS outputs low level.
Table 15 STATUS pin definition
Indicate working status
of the module
