Band2
1930~1990MHz
1850~1910MHz
Band3
1805~1880MHz
1710~1785MHz
Band4
2110~2155MHz
1710~1755MHz
Band5
869~894MHz
824~849MHz
Band8
926~960MHz
880~915MHz
Band12
729-746 MHz
699-716 MHz
Band13
746-756 MHz
777-787 MHz
Band14
758-768 MHz
788-798 MHz
Band18
860~874.9MHz
815~829.9MHz
Band19
875~889.9MHz
830~844.9MHz
Band20
791-821 MHz
832-862 MHz
Band25
1930-1995 MHz
1850-1915 MHz
Band26
859~894MHz
814~849MHz
Band27
852-869 MHz
807-824 MHz
Band28
758-803 MHz
703-748 MHz
Band66
2110-2200 MHz
1710-1780 MHz
Band71
617-652 MHz
663-698 MHz
Band85
TBD
TBD
5.2 RF Reference Circuit
RF_ANT antenna connection reference circuit is shown as follows. In order to gain better RF
performance, you need to reserve π-type matching circuit without mounting capacitor.
