5 Antenna Interface
Table 20 Pin definition of RF antenna
Pin name
Pin number
Description
I/O
Note
MAIN_ ANT
5
Mian antenna
IO
50Ω impedance
GNSS_ ANT
10
GNSS antenna
AI
50Ω impedance
5.1 Antenna Interface
SLM156 provides two antenna pins, which are MAIN_ ANT, GNSS_ ANT.
It is recommended that you use a 50Ω impedance antenna that matches the RF connector of the
module.
It is suggested that you chose RF adapter carefully on application end. It is necessary to select the
smallest possible loss of the RF adapter, and the recommended RF adapters are as follows:
 TD-LTE<1.5dB
 FDD LTE<1.5dB
5.1.1 Working Band
Table 21 Working band of the module
Network mode
Band
Receive
Transmit
GSM
GSM850
869~894 MHz
824~849 MHz
EGSM900
925~960
880~915 MHz
DCS1800
1805~1880
1710~1785 MHz
PCS1900
1930~1990
1850~1910 MHz
Cat M1 &NB1
Band1
2110~2170MHz
1920~1980MHz
