SECTION 4 - OPERATION
4OPERATION
4.1 Location and Description of Controls
Figure 4-1: Dishwasher controls
A - Wakeup key
Activates the machine from being turned off,
activating the display and other controls.
This key is also used to enter the service and
programming levels.
B - Display
Shows various information about the operating
status of the dishwasher, including:
• Operating state
• Wash tank temperature
• Final rinse temperature
• Selected cycle
C - Start key
Pressing the key once begins a wash cycle. The
color of the start key also provides information on
the dishwasher’s operating state:
• Blue (steady) - Ready for operation
• Blue (flashing) - Initial filling/heating in progress
• Green (steady) - Dish wash cycle in progress
• Green (flashing) - Memory-timed filling/heating
in progress
D - On/Off key
This key is disabled withn the machine is fully turned
off, and appears when the Wakeup key is pressed.
Pressing the key when the machine is off begins
the normal heating/filling process.
Pressing the key when the machine is on turns the
machine off.
E - Select/Confirm key
Cycles through various menu options when a or
(arrow) is shown on the display next to the key.
The current option choice is highlighted.
Confirms a menu selection when a (check mark)
is shown on the display next to the key.
Cancels a menu selection when a (back symbol)
is shown on the display next to the key.
F - Door handle (illuminated)
The color of the door handle provides information
on the dishwasher’s operating state:
• Blue (steady) - Ready for operation
• Blue (flashing) - Initial filling/heating in progress
• Green (pulsating slowly) - Dish wash cycle in
progress
• Green (flashing) - Wash cycle pending, filling/
heating in progress
• Red - Check display for an important message
