2. Specifications and Functions
2.1 Introduction
The TC68S is a user-friendly GPS vehicle tracker plugged into the vehicle’s OBD connector which can provide
vehicle positioning, tracking and anti-theft.
With standard OBD II plug, the TC68S can be easily and quickly installed.
When TC68S is being removed, it will send alert notification to mobile devices or servers.
The TC68S is suitable for all private cars and other vehicles with OBD II connector.
2.2 Specifications
Items Specification
Dimension 69.8*51.8*31.8 mm
Weight 60g
Input Voltage DC 12V/1A
Back-up Battery 150mAh/3.7V
Power Consumption 65mA
Operating Temperature
-20℃~55℃
Humidity 5%~95%
Work T ime 7 hours in power-saving mode and 1.5 hours in normal mode
LED 2 LED lights to show GPS/GSM status
Button 1 pc SOS button, 1 pc power button
Microphone Internal microphone
Memory 8MB
Sensor Tremble sensor
GSM Frequency GSM 850/900/1800/1900MHz
GPS Chipset Latest SIRF-Star IV
GPS Sensitivity -163dB
Positioning Accuracy 10 meters
Input/ Output 1 port for USB cable
2.3 Functions
2.3.1 GPS Tracking
Function Description
Real Time Tracking Send command to get real time location.
Timing Tracking Set time interval, the unit will, in accordance with the preset time, report location
Copyright © 2014 Meitrack Group All rights reserved. -4-
