No. Part (Description)
Warranty
coverage (year)
QTY No. Part (Description)
Warranty
coverage
(year)
QTY
1 Main lid A 1 1 41 Question mark burner gas valve 1 1
2 Main lid screw A 1 2 42 Rotisserie burner gas valve 1 1
3 Main lid screw B 1 2 43 Main manifold 1 1
4 Temperature gauge housing 1 1 44 Igniter junction wire 1 1
5 Temperature gauge 1 1 45 Control panel light 1 1
6 Hood buffer A 1 2 46 Tempered glass fix panel 1 1
7 Main lid handle A 1 1 47 Tempered glass 1 1
8 Main lid B 1 1 48 Main control panel 1 1
9 Main lid handle B 1 1 49 Light switch 1 1
10 Side shelf rear panel 1 1 50 Control knob bezel 1 5
11 Side shelf, left 1 1 51 Main burner control knob 1 4
12 Side shelf trim panel,left 1 1 52 Control knob A 1 2
13 Utensil hook 1 6 53 Grease tray 1 1
14 Logo 1 1 54 Question mark burner flame tamer 1 1
15 Side shelf control panel 1 1 55 Question mark burner pin assembly 1 2
16 Flame tamer 1 3 56 Question mark burner 5 1
17 Burner pin assembly 1 3 57 Main burner igniter wire D 1 1
18 Main burner 5 3 58 Spit fork 1 2
19 Main burner igniter wire A 1 1 59 Rotisserie motor bracket 1 1
20 Main burner igniter wire B 1 1 60 Rotisserie motor 1 1
21 Main burner igniter wire C 1 1 61 Spit rod 1 1
22 Warming rack 1 1 62 Igniter wire cover 1 1
23 Cooking grid A 3 1 63 Sear side burner lid 1 1
24 Cooking grid B 3 2 64 Sear side burner lid handle 1 1
25 Rotisserie burner flex gas line 1 1 65 Sear side burner cooking grate 1 1
26
Rotisserie burner
orifice with brass elbow
1 1 66 Sear side burner igniter wire 1 1
27
Rotisserie burner
igniter wire
1 1 67 Sear side control panel 1 1
28 Rotisserie burner heat shield 1 1 68 Sear side burner 1 1
29 Rotisserie burner 1 1 69 Sear side burner lid support bracket 1 1
30
Rotisserie burner igniter
bracket
1 2 70 Sear side burner bowl assembly 1 1
31 Back panel, top 1 1 71 Sear side burner rear panel 1 1
32
Question mark burner bowl
assembly
Non-replaceable 1 72 Sear side burner grease box 1 1
33 Firebox junction Clapboard 1 1 73 Side shelf trim panel, right 1 1
34 Main burner bowl assembly Non-replaceable 1 74 Side panel, right 1 1
35 Front Baffle 1 1 75 Grease box 1 1
36 Main gas valve 1 3 76 Drawer Heat shield, left 1 1
37 Regulator LP 1 1 77 Drawer 1 2
38 Sear side burner gas valve 1 1 78 Drawer slide 1 4
39 Sear side burner manifold 1 1 79 Door handle 1 3
40 Sear side burner flex gas line 1 1 80 Battery box 1 1
Part List
8
