29
Specifications
1. General Specifications
Frequency Range (15CH GMRS) 462.5500 - 462.7250
Channel Spacing 12.5KHz
Sub-Tone Code(CTCSS) 38 for each main channel
Dimension w/o Antenna
127mm(H) x 61mm(W) x 34mm(D)
Standard Batteries
Alkaline 2400mA AA(4), 6VDC
Rechargeable Batteries
Ni-MH 1200mA AA(4), 4.8VDC
Operation Time (5-5-90) 37 hours at Hi power
57 hours at Low power
2. Receiver
Useable Sensitivity > -119 dBm
Maximum Audio Output Power > 0.3 Watt Max (8 Ohm)
Modulation Distortion < 5%(1 KHz 70%)
3. Transceiver
RF Output Power
1.8W Max(at Hi)/0.5W Max(at Low)
Max Deviation +/- 2.5 KHz
Modulation Distortion < 5%(1 KHz 70%)
