ELECTRICAL REPLACEMENT PARTS LIST

REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION

ICS TRANSISTORS

! IC3802 I0QD023680 IC NJM2368D Q8502 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK

! IC3803 000220001W PHOTO COUPLER PS2561L1-1-V(W) Q8503 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK

IC4002 I5PK055890 IC STM5589AVA Q8505 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK

IC4003 I5CF0CU040 IC SN74AHCU04PWR Q8506 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK

IC4007 IF8J064007 IC IS42S16400-7T Q8507 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK

IC4012 I5PJ060ET9 IC M29W160ET90N6 Q8508 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK

IC4201 I0QF045800 IC NJM4580M

COILS &TRANSFORMERS

IC4202 I0UF015020 IC MM1502XNRE L001 021375101K COIL 100 UH

IC8501 I0GF9XZ010 IC PQ070XZ01ZP L101 0216A6560K COIL 56 UH

IC8502 I17F0742K0 IC PCM1742KE/2K L401 021679472K COIL 4.7 MH

IC8503 I0GF9M3350 IC PQ1M335M2SP L601 02167F101J COIL 100 UH

IC8504 I0GF9XZ010 IC PQ070XZ01ZP L602 021375101K COIL 100 UH

TRANSISTORS

L801 021673560K COIL 56 UH

Q105 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L902 02167F101J COIL 100 UH

Q106 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK L904 02167F101J COIL 100 UH

Q301 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L2001 0216S4100J COIL 10 UH

Q302 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L2002 0216S4100J COIL 10 UH

Q305 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L2004 02167F2R7J COIL 2.7 UH

! Q402 TF2002P4M0 THYRISTOR 2P4M L3001 02167E100K COIL 10 UH

Q403 TPAAB05001 COMPOUND TRANSISTOR KRA102SRTK L3002 02167E100K COIL 10 UH

! Q405 TCAT03227Y TRANSISTOR SILICON KTC3227_Y-AT ! L3800 028R090008 COIL,DEGAUSS 8R090008

! Q406 TD3Q021400 TRANSISTOR SILICON TT2140LS-YBC11 L3801 021767100K COIL 10 UH

Q601 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK ! L3802 029T000092 COIL,LINE FILTER 1R0A103F24

Q602 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L3803 02A6B2E0A1 CORE,FERRITE HF70T22*10*14

Q605 TPYJB05001 COMPOUND TRANSISTOR DTA114EKAT146 L4001 02167F220J COIL 22 UH

! Q804 TCAT032070 TRANSISTOR SILICON KTC3207-AT L4002 02167F220J COIL 22 UH

! Q805 TCAT032070 TRANSISTOR SILICON KTC3207-AT L4003 02167F220J COIL 22 UH

! Q806 TCAT032070 TRANSISTOR SILICON KTC3207-AT L4004 02167F220J COIL 22 UH

Q901 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK L4201 02167F101J COIL 100 UH

Q902 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK L4202 02167F101J COIL 100 UH

Q2001 T67J1036K0 TRANSISTOR SILICON 2SA1036KT146 L4203 02167F101J COIL 100 UH

Q2002 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S L4204 021673101K COIL 100 UH

Q2003 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L8501 02167F2R2J COIL 2.2 UH

Q2004 T27T030180 FET 2SK3018 L8502 02167F2R2J COIL 2.2 UH

Q2005 T27T030180 FET 2SK3018 L8503 02167F2R2J COIL 2.2 UH

Q2006 T67J1036K0 TRANSISTOR SILICON 2SA1036KT146 L8504 02AHB9A972 CORE,FERRITE W5T29X7.5X19

Q2007 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK L8507 02167F2R2J COIL 2.2 UH

Q2008 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK T401 045009003J TRANS,HORIZONTAL DRIVE ETH09K14BZ

Q2201 TNYJC05001 COMPOUND TRANSISTOR DTC124EKAT146 ! T3801 0481350574 TRANSFORMER,SWITCHING 81350574

! Q3000 TAAT01281Y TRANSISTOR SILICON KTA1281_Y ! T3802 0481291124 TRANSFORMER,SWITCHING 81291124

Q3001 TNYJB05001 COMPOUND TRANSISTOR DTC114EKAT146

JACKS

Q3002 TCAT03209Y TRANSISTOR SILICON KTC3209_Y-AT ! J801 066F120018 SOCKET,CATHODE RAY TUBE ISMS01S

! Q3003 TBA0013660 TRANSISTOR SILICON KTB1366(O,Y) ! J2201 060J131015 HEADPHONE JACK MSJ-2000

! Q3004 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT J2202 060G421016 RCA JACK HTJ-032-05AY

! Q3005 TCAT03209Y TRANSISTOR SILICON KTC3209_Y-AT J2203 060G421017 RCA JACK HTJ-032-05AW

! Q3006 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT J2204 060G421020 RCA JACK HTJ-032-05AR

Q3007 TAAT01281Y TRANSISTOR SILICON KTA1281_Y ! J3801 0602602006 JACK DC HEC0824-010010

! Q3008 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT J4201 060J411025 RCA JACK

MSP-244V10-44PBSN

Q3009 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT

SWITCHES

Q3010 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK SW2213 0504101T34 SWITCH,TACT EVQ21505R

Q3012 TPYJC05001 COMPOUND TRANSISTOR DTA124EKAT146 SW2214 0504101T34 SWITCH,TACT EVQ21505R

Q3013 TNYJB05001 COMPOUND TRANSISTOR DTC114EKAT146 SW2215 0504101T34 SWITCH,TACT EVQ21505R

! Q3802 TCAT03209Y TRANSISTOR SILICON KTC3209_Y-AT SW2216 0504101T34 SWITCH,TACT EVQ21505R

Q3803 TNATB03005 COMPOUND TRANSISTOR KRC102MAT SW2217 0504101T34 SWITCH,TACT EVQ21505R

! Q3804 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) SW2218 0504101T34 SWITCH,TACT EVQ21505R

! Q3805 TAAT012714 TRANSISTOR, SILICON KTA1271_Y-AT SW2219 0504101T34 SWITCH,TACT EVQ21505R

Q3806 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) SW2220 0504101T34 SWITCH,TACT EVQ21505R

! Q3807 T410029030 FET 2SK2903-01MR SW2221 0504101T34 SWITCH,TACT EVQ21505R

Q3808 TNATB03005 COMPOUND TRANSISTOR KRC102MAT SW2223 0504101T34 SWITCH,TACT EVQ21505R

Q3810 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR)

VARIABLE RESISTORS

! Q3811 TJXG5NC500 FET STP5NC50FP VR401 V1K63Q3BTE VOLUME,SEMI FIXED NVG6TLTAB472

! Q3812 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT VR3801 V1K6314BTE VOLUME,SEMI FIXED NVG6TLTAB103

Q4001 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK VR3802 V1163Q3BTC VOLUME,SEMI FIXED EVNCYAA03BQ3

Q4002 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK

P.C.BOARD ASSEMBLIES

Q4003 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK PCB020 A5G607I020 PCB ASS'Y VPB164A

Q4201 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK PCB110 A5G607I110 PCB ASS'Y TCB422A

Q4203 TNAAD05001 COMPOUND TRANSISTOR KRC104SRTK PCB130 A5G607I130 PCB ASS'Y VMC303A

Q4204 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK PCB250 A5G607I250 PCB ASS'Y TMB560A

Q4205 TPYJB05001 COMPOUND TRANSISTOR DTA114EKAT146

MISCELLANEOUS

Q4206 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK ANT001 125C108027 ANTENNA ROD T4-216BNK-BK

Q4207 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B401 024HT03553 CORE,BEADS W5RH3.5X5X1.0

Q4208 TAATA12660 TRANSISTOR,SILICON KTA1266-AT(Y,GR) B2001 024HC31022 CORE,BEADS FCM2012H-102T04

Q4209 TNYJC05001 COMPOUND TRANSISTOR DTC124EKAT146 B2002 024HC31022 CORE,BEADS FCM2012H-102T04

Q4210 TPYJA05001 COMPOUND TRANSISTOR DTA143EKAT146 B2003 024HC31022 CORE,BEADS FCM2012H-102T04

Q4211 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2004 024HC31022 CORE,BEADS FCM2012H-102T04

Q4212 TCAA3875SY TRANSISTOR SILICON KTC3875S_Y_RTK B2005 024HC31022 CORE,BEADS FCM2012H-102T04

Q8501 TAAA1504SY TRANSISTOR SILICON KTA1504S_Y_RTK B2301 024HC31022 CORE,BEADS FCM2012H-102T04

J2-2
