ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION RESISTOR
MISCELLANEOUS
RC................... CARBON RESISTOR
B3801 024HT03564 CORE,BEADS W4BRH3.5X6X1.0
B3802 024HT03564 CORE,BEADS W4BRH3.5X6X1.0 CAPACITORS
B3803 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CC................... CERAMIC CAPACITOR
B3804 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CE................... ALUMI ELECTROLYTIC CAPACITOR
B3805 024HT03563 CORE,BEADS W4BRH3.5X6X1.0X2 CP................... POLYESTER CAPACITOR
B3806 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CPP.................. POLYPROPYLENE CAPACITOR
B4002 024HC31022 CORE,BEADS FCM2012H-102T04 CPL.................. PLASTIC CAPACITOR
B4004 024HC31022 CORE,BEADS FCM2012H-102T04 CMP..................
METAL POLYESTER CAPACITOR
B4201 024HT03553 CORE,BEADS W5RH3.5X5X1.0 CMPL................ METAL PLASTIC CAPACITOR
B8501 024HC31022 CORE,BEADS FCM2012H-102T04 CMPP................ METAL POLYPROPYLENE CAPACITOR
B8502 024HC31022 CORE,BEADS FCM2012H-102T04
B8503 024HC31022 CORE,BEADS FCM2012H-102T04
B8505 024HT03563 CORE,BEADS W4BRH3.5X6X1.0X2
! CD504 121B164101 CORD,CAR BATTERY SI-PC107-67
CD802 WDL6032038 FLAT CABLE
AWG26 6C BLACK 320MM
CD803 WBL6030038 FLAT CABLE AWG26 4C BLACK 300MM
CD805 06CU82039A CORD CONNECTOR SM1098-009-1A
CP101 069S270639 CONNECTOR PCB SIDE A2001WR2-7P
CP301 069W120019 CONNECTOR PCB SIDE TID-X02P-B2
CP302 069W120019 CONNECTOR PCB SIDE TID-X02P-B2
! CP401 069X440029 CONNECTOR PCB SIDE B04B-DVS
CP402 067U003029 WIRE HOLDER B2013H02-3P
CP403 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
CP801 069S320010 CONNECTOR PCB SIDE A2361WV2-2P
CD2001 122H0O1902 CORD JUMPER 2H0O1902
CD3001 WFL6022038 FLAT CABLE
AWG26 8C BLACK 220MM
! CD3801 120R414903 CORD AC BUSH 0R414903
CD8501 122H0C1001 CORD JUMPER 2H0C1001
CD8505 06CU2B2001 CORD CONNECTOR CU2B2001
CP2001 069RYOT109 CONNECTOR PCB SIDE 52975-2492
CP2301 069EV53020 CONNECTOR PCB SIDE 00_6232_005_102_800
CP2302 069EV43020 CONNECTOR PCB SIDE 00_6232_004_102_800
CP2303 069EVC3020 CONNECTOR PCB SIDE 00_6232_012_102_800
CP3001 067U008029 WIRE HOLDER B2013H02-8P
CP3802 069R230589 CONNECTOR PCB SIDE 52147-0310
CP3803 069R280589 CONNECTOR PCB SIDE 52147-0810
CP8001 069S2B0629 CONNECTOR PCB SIDE A2001WV2-11P
CP8002 069J7C0029 CONNECTOR PCB SIDE IMSA-9604S-12Z14
CP802A 067U006049 WIRE HOLDER B2013H02-6P
CP802B 067U006049 WIRE HOLDER B2013H02-6P
CP803A 067U004029 WIRE HOLDER B2013H02-4P
CP803B 067U004029 WIRE HOLDER B2013H02-4P
CP8502 069J7C0019 CONNECTOR PCB SIDE IMSA-9604S-12Z13
CUS251 800WFAA008 CUSHION C
! DK4001 169E00026A DECK CD CV-VLM102
EL001 124120301A EYE LET XRY20X30BD
EL002 124116281A EYE LET XRY16X28BD
EL003 124120301A EYE LET XRY20X30BD
EL004 124116281A EYE LET XRY16X28BD
! F3801 081PC05005 FUSE 51MS050L
! F3802 0835C10003 MICRO FUSE 20N_10KFS
! FB401 043210014F TRANSFORMER,FLYBACK FNI-10B001
FH3801 06710T0006 HOLDER,FUSE EYF-52BC
FH3802 06710T0006 HOLDER,FUSE EYF-52BC
OS2202 077Q037007 REMOTE RECEIVER PIC-37143SY-H
! RY3801 0560V10118 RELAY ALKS325
! SP301 070C132019 SPEAKER SA08A05BWC
! SP302 070C132019 SPEAKER SA08A05BWC
TM101 076R0DT160 TRANSMITTER R25-1948
! TU001 0163300005 RF UNIT 115-V-K015AR_B
! V801 0981100405 CRT W/DY A22JWG098X82
X101 1002T01606 CERAMIC OSCILLATOR CSTLS16M0X53-A0
X601 100CT3R505 CRYSTAL HC-49/C
X2001 100BT02003 CRYSTAL HC-49U/S
X4001 100BT02701 CRYSTAL HC-49U/S
J2-3
