D2-4
MECHANICAL ADJUSTMENTS
3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE
5
6
7
89
10
1
2
3
4
1. Tension Connect
2. Tension Arm
3. Guide Roller
4. Audio/Control Head
5. X value adjustment driver hole
6.
7.
8.
9.
10.
P4 Post
T Brake Spring
T Reel
S Reel
Adjusting section for the Tension Arm position
