Memorex MVT2137 User Manual

ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
RESISTORS DIODES
! R404 R4X5T6152F R,METAL 1.5K OHM 1/6W ! D411 D2LTPG06J0 DIODE SILICON RMPG06J-G3
! R409 R3X181221J R,METAL OXIDE 220 OHM 1W ! D412 D2LTPG06J0 DIODE SILICON RMPG06J-G3
! R432 R655U2010J R,FUSE 1 OHM 1/2W ! D413 D2LTPG06J0 DIODE SILICON RMPG06J-G3
! R442 R4X5T6123F R,METAL 12K OHM 1/6W D501 D97U01001B DIODE,ZENER MTZJ10B T-77
! R443 R4X5T6272F R,METAL 2.7K OHM 1/6W D502 D1VT001330 DIODE,SILICON 1SS133T-77
! R447 R65582680J R,FUSE 68 OHM 1/2W ! D503 D2WTRM11C0 DIODE SILICON RM11C-EIC
! R450 R635813R9J R,FUSE 3.9 OHM 1W ! D504 D2WTRM11C0 DIODE SILICON RM11C-EIC
! R500 R0G3K2275K RC 2.7M OHM 1/2W D505 D94TA27011 DIODE ZENER HZ27-1L TD
! R501 R5Y2CD010J R,CEMENT 1 OHM 5W or D506 D230PF6DT0 DIODE SILICON FEPF6DT
R5X2CD010J R,CEMENT 1 OHM 5W ! D507 D97U01801B DIODE,ZENER MTZJ18B T-77
! R502 R3X28B100J R,METAL OXIDE 10 OHM 3W D508 D1VT001330 DIODE,SILICON 1SS133T-77
! R505 R002T2563J RC 56K OHM 1/2W ! D509 D2WXRU2AM0 DIODE SILICON RU2AM-EIC
! R510 R002T2155J RC 1.5M OHM 1/2W ! D510 D2WXRU2AM0 DIODE SILICON RU2AM-EIC
! R511 R002T4105J RC 1M OHM 1/4W D511 D28TELS6N6 DIODE RECTIFIER 10ELS6N-TA1B2
! R513 R002T4102J RC 1K OHM 1/4W D512 D2WT011E10 DIODE SILICON 11E1-EIC
! R520 R002T4102J RC 1K OHM 1/4W D513 D2WT011E10 DIODE SILICON 11E1-EIC
! R528 R63581R22J R,FUSE 0.22 OHM 1W D514 D1VT001330 DIODE,SILICON 1SS133T-77
! R529 R002T4182J RC 1.8K OHM 1/4W ! D515 D97U03301B DIODE,ZENER MTZJ33B T-77
R530 R3X181R18J R,METAL OXIDE 0.18 OHM 1W D516 D1VT001330 DIODE,SILICON 1SS133T-77
! R545 R3X181331J R,METAL OXIDE 330 OHM 1W D517 D1VT001330 DIODE,SILICON 1SS133T-77
! R547 R3X28B4R7J R,METAL OXIDE 4.7 OHM 3W D518 D2LTPG06J0 DIODE SILICON RMPG06J-G3
R695 R00204103J RC 10K OHM 1/4W D519 D1VT001330 DIODE,SILICON 1SS133T-77
! R802 R3X18A153J R,METAL OXIDE 15K OHM 2W D520 D1VT001330 DIODE,SILICON 1SS133T-77
! R805 R3X18A153J R,METAL OXIDE 15K OHM 2W D521 D2WXB290S0 DIODE SILICON SB290S
! R810 R3X18A153J R,METAL OXIDE 15K OHM 2W D522 D97U01601B DIODE ZENER MTZJ16B T-77
CAPACITORS
D523 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
C321 E0EL02332M CE 3300 UF 16V or D524 D1VT001330 DIODE,SILICON 1SS133T-77
E02L02332M CE 3300 UF 16V D528 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
! C402 E5EZTD2R2M CE 2.2 UF 250V D530 D1VT001330 DIODE,SILICON 1SS133T-77
! C405 E02LU5010M CE 1 UF 50V ! D531 D2WXB290S0 DIODE SILICON SB290S
! C406 E5EZU4101M CE 100 UF 35V D533 D2WXN49370 DIODE SILICON 1N4937
! C407 E02LF3102M CE 1000 UF 25V D534 D97U02001B DIODE,ZENER MTZJ20B T-77
C413 P21503475K CMP 4.7 UF 250V ECQ-E ! D535 D2WTRM11C0 DIODE SILICON RM11C-EIC
C414 P21503475K CMP 4.7 UF 250V ECQ-E ! D536 D2WTRM11C0 DIODE SILICON RM11C-EIC
C421 E5EZ04102M CE 1000 UF 35V ! D537 D2WXB290S0 DIODE SILICON SB290S
! C422 E5EZTD010M CE 1 UF 250V ! D539 D2WT011E10 DIODE SILICON 11E1-EIC
! C423 P4J7F3394J CMPP 0.39 UF 250V PMS or ! D540 D2WT011E10 DIODE SILICON 11E1-EIC
P411F3394J CMPP 0.39 UF 250V ECWF ! D541 D2WT011E10 DIODE SILICON 11E1-EIC
! C424 P414F9682H CMPP 0.0068UF 1.6KV ECW or ! D542 D28XELS2N2 DIODE RECTIFIER 10ELS2N-TA2B5
P4N8FJ682H CMPP 0.0068UF 1.25KV ! D545 D2WXB290S0 DIODE SILICON SB290S
C425 C03L0R713K CC 0.001 UF 2KV R D546 D1VT001330 DIODE,SILICON 1SS133T-77
C426 C0PLRR713K CC 0.001 UF 2KV RR D547 D1VT001330 DIODE,SILICON 1SS133T-77
C430 C0PLRR713K CC 0.001 UF 2KV RR ! D548 D1VT001330 DIODE,SILICON 1SS133T-77
! C433 E02LU8220M CE 22 UF 100V D550 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
! C502 C0JBB05H3K CC 0.0022UF 500V B or D551 D97U02R21B DIODE,ZENER MTZJ2.2B T-77
C034BN7H3K CC 0.0022UF 2KV BN D601 D1VT001330 DIODE,SILICON 1SS133T-77
! C503 C0JBB05H3K CC 0.0022UF 500V B or D602 D97U08R21C DIODE,ZENER MTZJ8.2C T-77
C034BN7H3K CC 0.0022UF 2KV BN D603 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
! C505 P2472B224M CMP 0.22UF 275V PHE840 D605 D28T11ESN1 DIODE SILICON 11ES1N-TA1B2
! C507 E51CGC471M CE 470 UF 200V or D606 D97U01101B DIODE,ZENER MTZJ11B T-77
E51CFC471M CE 470 UF 200V D607 D1VT001330 DIODE,SILICON 1SS133T-77
C513 C0PLRR713K CC 0.001 UF 2KV RR or D608 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
C03L0R713K CC 0.001 UF 2KV R D609 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
C515 E62FF3152M CE 1500 UF 25V D610 D2WXSB1400 DIODE SCHOTTKY SB140-EIC
C518 C03L0R7K3K CC 0.0027UF 2KV R D611 D2WXSB1400 DIODE SCHOTTKY SB140-EIC
C519 CB3930M13M CC 0.001 UF 250V D612 D97U06R81B DIODE,ZENER MTZJ6.8B T-77
C520 CB3930M13M CC 0.001 UF 250V D616 D1VT001330 DIODE,SILICON 1SS133T-77
C523 CB3930MH3M CC 0.0022UF 250V D617 D1VT001330 DIODE,SILICON 1SS133T-77
C525 C0PLRR713K CC 0.001 UF 2KV RR D618 D1VT001330 DIODE,SILICON 1SS133T-77
! C534 E62NFC101M CE 100 UF 200V D619 D1VT001330 DIODE,SILICON 1SS133T-77
C535 E5EZF2222M CE 2200 UF 16V D620 D1VT001330 DIODE,SILICON 1SS133T-77
! C536 E5EZF3102M CE 1000 UF 25V D621 D1VT001330 DIODE,SILICON 1SS133T-77
! C537 E5EZF3102M CE 1000 UF 25V D791 0021E2Q150 LED LTL-4224-031A or
! C538 E02LU5470M CE 47 UF 50V 002132Q040 LED SLZ-936C-11-S-T1
! C540 E02LU50R1M CE 0.1 UF 50V D792 0021E2Q150 LED LTL-4224-031A or
C544 E5EZF3102M CE 1000 UF 25V 002132Q040 LED SLZ-936C-11-S-T1
C551 E62FF3152M CE 1500 UF 25V D793 0021E2Q150 LED LTL-4224-031A or
C801 C0PLRR713K CC 0.001 UF 2KV RR 002132Q040 LED SLZ-936C-11-S-T1
DIODES
D1002 D1VT001330 DIODE,SILICON 1SS133T-77
D401 D2WT011E10 DIODE SILICON 11E1-EIC D1003 0010100320 INFRARED LED LNA2702L010R
D402 D2LTPG06J0 DIODE SILICON RMPG06J-G3 D1004 D97U03R91B DIODE,ZENER MTZJ3.9B T-77
D403 D97U06R81B DIODE,ZENER MTZJ6.8B T-77 D1014 D97U05R11B DIODE,ZENER MTZJ5.1B T-77
D404 D1VT001330 DIODE,SILICON 1SS133T-77 D4004 D1VT001330 DIODE,SILICON 1SS133T-77
D405 D1VT001330 DIODE,SILICON 1SS133T-77 D4201 D97U05R61B DIODE,ZENER MTZJ5.6B T-77
D406 D97U03001B DIODE,ZENER MTZJ30B T-77 D4206 D97U01301B DIODE,ZENER MTZJ13B T-77
D407 D97U03001B DIODE,ZENER MTZJ30B T-77
ICS
! D409 D94TA11B13 DIODE ZENER HZ11B3L TD ! IC351 I0FSP75230 IC AN7523 or
J3-1
