ELECTRICAL REPLACEMENT PARTS LIST

REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION

ICS COILS &TRANSFORMERS

IC351 I0FSP7523N IC AN7523N L503 021767100K COIL 10 UH

! IC401 I01TD55220 IC AN5522 ! L508 028R140024 COIL,DEGAUSS 8R140024

! IC501 I1KA97805A IC KIA7805API L604 02167F101J COIL 100 UH

! IC504 I0QD023680 IC NJM2368D L607 021LA6180K COIL 18 UH

! IC506 0002E00610 PHOTO COUPLER LTV-817M-VB L608 02167F101J COIL 100 UH

IC601 I06FC61206 IC M61206FP L610 021375101K COIL 100 UH

! IC603 I1KA98R050 IC KIA78R05PI L614 021LA66R8K COIL 6.8 UH

IC1001 I56F57071A IC OEC7071A L615 021375101K COIL 100 UH

IC1002 IC7J0311A0 IC R3111N311A/C-TR L801 021673101K COIL 100 UH

IC1099 A5A3A9C015 IC S-24C04BDP-LA L1001 021LA62R2K COIL 2.2 UH

IC4001 I03F3205M0 IC LA71205M-MPB L4001 02167F220J COIL 22 UH

TRANSISTORS

L4003 02167F101J COIL 100 UH

Q350 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S L4005 02167F470J COIL 47 UH

Q401 TPATB03003 COMPOUND TRANSISTOR KRA102MAT L4006 02167F470J COIL 47 UH

Q402 TF2002P4M0 THYRISTOR 2P4M L4007 032623004T COIL TRAP STP-01064 or

Q404 TNATJ03003 COMPOUND TRANSISTOR KRC111MAT 0326230038 COIL,TRAP 2623003

! Q405 TC5T01627Y TRANSISTOR SILICON 2SC1627_Y(TPE2) L4008 02167F101J COIL 100 UH

! Q406 TD30026270 TRANSISTOR SILICON 2SD2627LS-CBC11 L4009 02167F220J COIL 22 UH

Q407 TPATB03003 COMPOUND TRANSISTOR KRA102MAT L4205 02167F101J COIL 100 UH

Q408 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) T401 045009003J TRANS,HORIZONTAL DRIVE ETH09K14BZ

Q501 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) ! T501 0481290804 TRANSFORMER,SWITCHING 81290804

! Q502 TC5T021204 TRANSISTOR,SILICON 2SC2120Y(TPE2) ! T502 048133020S TRANSFORMER,SWITCHING 8133020S

Q503 TNATJ03003 COMPOUND TRANSISTOR KRC111MAT T4001 031626009R COIL,BIAS OSC 1626009

! Q505 T410032730 FET 2SK3273-01MR

JACKS

Q507 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) J351 060G131014 RCA JACK HTJ-035-28A

Q509 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) ! J503 0602602006 JACK DC HEC0824-010010

Q510 TJXG5NC500 FET STP5NC50FP J701 060Q401075 RCA JACK AV2-24D-5

Q511 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) ! J801 066X120014 SOCKET,CATHODE RAY TUBE HPS3200-010501

Q512 TAAT012714 TRANSISTOR, SILICON KTA1271_Y-AT J4201 060Q401050 RCA JACK AV2-20D-2

Q514 TNATB03005 COMPOUND TRANSISTOR KRC102MAT or J4202 060Q401050 RCA JACK AV2-20D-2

TNYTB03001 COMPOUND TRANSISTOR DTC114ESTP

SWITCHES

Q516 TNATJ03003 COMPOUND TRANSISTOR KRC111MAT SW751 0504101T34 SWITCH,TACT EVQ21505R

Q518 TNATB03005 COMPOUND TRANSISTOR KRC102MAT or SW791 0504101T34 SWITCH,TACT EVQ21505R

TNYTB03001 COMPOUND TRANSISTOR DTC114ESTP SW792 0504101T34 SWITCH,TACT EVQ21505R

Q601 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S SW793 0504101T34 SWITCH,TACT EVQ21505R

Q604 TPAAB05001 COMPOUND TRANSISTOR KRA102SRTK SW794 0504101T34 SWITCH,TACT EVQ21505R

! Q605 TC10013840 TRANSISTOR SILICON 2SC13840W SW795 0504101T34 SWITCH,TACT EVQ21505R

! Q606 TC10013840 TRANSISTOR SILICON 2SC13840W SW796 0504101T34 SWITCH,TACT EVQ21505R

Q607 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S SW797 0504101T34 SWITCH,TACT EVQ21505R

! Q608 TC10013840 TRANSISTOR SILICON 2SC13840W SW798 0504101T34 SWITCH,TACT EVQ21505R

Q609 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S SW799 0504101T34 SWITCH,TACT EVQ21505R

Q610 TB3T011310 TRANSISTOR SILICON 2SB1131(S,T)-AE SW1001 0508A11002 SWITCH(LEAF) MXS01380MPP0

Q611 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK

VARIABLE RESISTORS

Q651 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S VR401 V1K63Q4BTE VOLUME,SEMI FIXED NVG6TLTAB473

! Q804 TCA0042170 TRANSISTOR SILICON KTC4217(O,Y) VR402 V1K63H3BTE VOLUME,SEMI FIXED NVG6TLTAB222

! Q805 TCA0042170 TRANSISTOR SILICON KTC4217(O,Y) VR501 V1163H3BTC VOLUME,SEMI FIXED EVNCYAA03BE3

! Q806 TCA0042170 TRANSISTOR SILICON KTC4217(O,Y) VR502 V1163Q3BTC VOLUME,SEMI FIXED EVNCYAA03BQ3

Q1002 0000M00390 PHOTO TRANSISTOR ST-304L

P.C.BOARD ASSEMBLIES

Q1003 0002700680 PHOTO COUPLER RPI-352C40N or PCB010 A5A3A9C010 PCB ASS'Y VMA245B

0002700670 PHOTO COUPLER RPI-352Q02 PCB030 A5A3A0I030 PCB ASS'Y TE9980B

Q1004 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK PCB070 A5A3A0I070 PCB ASS'Y TMA527A

Q1005 0002700690 PHOTO COUPLER RPI-303 or PCB110 A5A3A0I110 PCB ASS'Y TCA386A

0002700590 PHOTO COUPLER RPI-301

MISCELLANEOUS

Q1006 TNAAC05002 COMPOUND TRANSISTOR KRC103SRTK ! ANT001 125C108027 ANTENNA ROD T4-216BNK-BK

Q1008 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S B301 024HT03553 CORE,BEADS W5RH3.5X5X1.0

Q1009 0002700680 PHOTO COUPLER RPI-352C40N or B501 024HT03564 CORE,BEADS W4BRH3.5X6X1

0002700670 PHOTO COUPLER RPI-352Q02 B502 024HT03553 CORE,BEADS W5RH3.5X5X1.0

Q1013 0000M00390 PHOTO TRANSISTOR ST-304L B503 024HT03564 CORE,BEADS W4BRH3.5X6X1

Q4001 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) B505 024HT03553 CORE,BEADS W5RH3.5X5X1.0

Q4002 TCATC31980 TRANSISTOR,SILICON KTC3198-AT(Y,GR) B507 024HT03553 CORE,BEADS W5RH3.5X5X1.0

Q4003 TPAAC05002 COMPOUND TRANSISTOR KRA103SRTK CD351 06CU272301 CORD CONNECTOR CU272301

Q4005 TAATA12660 TRANSISTOR,SILICON KTA1266-AT(Y,GR) CD352 06CU12441A CORD CONNECTOR CU12441A

Q4006 TCAT032034 TRANSISTOR, SILICON KTC3203_Y-AT ! CD501 120R414903 CORD AC BUSH 0R414903

Q4007 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S CD502 06CH01423A CORD CONNECTOR CH01423A

Q4009 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S ! CD504 121B164101 CORD,CAR BATTERY SI-PC107-67

Q4010 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S CD601 06CH01006A CORD CONNECTOR CH01006A

Q4012 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S CD757 06CU2A2501 CORD CONNECTOR CU2A2501

Q4013 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S CD801 06CU82039A CORD CONNECTOR SM1098-009-1A

Q4204 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK CD803 WDL6026038 FLAT CABLE AWM2468 AWG26 6C BLACK 260MM

Q4205 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK CD810 WJL6830038 FLAT CABLE AWM2468 AWG26 11C GRAY 300 MM

Q4206 TNAAB05003 COMPOUND TRANSISTOR KRC102SRTK CD820 WKL6026038 FLAT CABLE AWM2468 AWG26 12C BLACK 260MM

Q4210 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S CD850 WCL6830038 FLAT CABLE AWM2468 AWG26 5C GRAY 300MM

Q4211 T8YJ2412K0 TRANSISTOR SILICON 2SC2412KT146 R,S CF601 1029045R7G FILTER,SAW TSF5229P3

Q4212 T6YJ1037K0 TRANSISTOR,SILICON 2SA1037AKT146R,S CF603 1011T4R504 FILTER,CERAMIC EFCT4R5YS5A

COILS &TRANSFORMERS

CF604 1011T4R517 FILTER,CERAMIC EFCT4R5MW5

L401 021679472K COIL 4.7 MH CP401 069S450089 CONNECTOR PCB SIDE A1561WV2-A5P

! L501 029T000092 COIL,LINE FILTER 1R0A103F24 CP402 069W01001A CONNECTOR PCB SIDE 003P-2100

J3-2
