ELECTRICAL REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION
MISCELLANEOUS
! CP403 069S420110 CONNECTOR PCB SIDE A1561WV2-2P
CP502 069R2B0589 CONNECTOR PCB SIDE 52147-1110
CP601 069W01001A CONNECTOR PCB SIDE 003P-2100
CP602 069X170379 CONNECTOR PCB SIDE 07JQ-ST
CP605 069R220021 CONNECTOR PCB SIDE 52287-0211
CP801 069S320010 CONNECTOR PCB SIDE A2361WV2-2P
CP820 069R2C0589 CONNECTOR PCB SIDE 52147-1210
CP850 069R250589 CONNECTOR PCB SIDE 52147-0510
CD4001 122F061502 CORD JUMPER 2F061502 or
122L061501 CORD JUMPER 2L061501
CP1001 06972C0010 CONNECTOR PCB SIDE TMC-J12P-B2
CP2201 069S2A0629 CONNECTOR PCB SIDE A2001WV2-10P
CP4001 0697240600 CONNECTOR PCB SIDE TOC-C04X-B1
CP4002 069J760029 CONNECTOR PCB SIDE IMSA-9604S-06Z14
CP4003 0697120320 CONNECTOR PCB SIDE TMC-T02X-E1
CP4202 069S270629 CONNECTOR PCB SIDE A2001WV2-7P
CP803A 067U006049 WIRE HOLDER B2013H02-6P
CP803B 069R260589 CONNECTOR PCB SIDE 52147-0610
CP805B 067U005049 WIRE HOLDER B2013H02-5P
CP810B 067U011029 WIRE HOLDER B2013H02-11P
CP820B 067U013029 WIRE HOLDER B2013H02-13P
CUS012 800WFAA007 CUSHION B
CUS013 800WFAA008 CUSHION C
EL001 124116281A EYE LET XRY16X28BD
EL002 124120301A EYE LET XRY20X30BD
! F501 081PC05004 FUSE 51MS050LCC or
081PA05003 FUSE 233005-MB000
! F502 081PC2R504 FUSE 51MS025LCC
! FB401 043214034F TRANSFORMER,FLYBACK 3214034F
FH501 06710T0006 HOLDER,FUSE EYF-52BC
FH502 06710T0006 HOLDER,FUSE EYF-52BC
FH503 06710T0006 HOLDER,FUSE EYF-52BC
FH504 06710T0006 HOLDER,FUSE EYF-52BC
! ICP502 0835C10003 MICRO FUSE 20N_10KFS
OS753 077Q037002 REMOTE RECEIVER PIC-37143TH5
! RY503 0560V10118 RELAY ALKS325
! SP351 070C533019 SPEAKER SG04D11BNA
TM101 076R0CG020 TRANSMITTER R25-1729
! TU601 0145K00056 TUNER,VHF-UHF TECC1040PG32E
! V801 098Y1404B9 CRT W/DY A34JXV70X53N45
X602 100CT3R505 CRYSTAL HC-49/C
X1001 100CT01207 CRYSTAL HC-49/U-S
X1002 100DA32R01 CRYSTAL DT-26
X4001 100CT3R502 CRYSTAL HC-49/U
RESISTOR
RC................... CARBON RESISTOR
CAPACITORS
CC................... CERAMIC CAPACITOR
CE................... ALUMI ELECTROLYTIC CAPACITOR
CP................... POLYESTER CAPACITOR
CPP.................
POLYPROPYLENE CAPACITOR
CPL.................. PLASTIC CAPACITOR
CMP................. METAL POLYESTER CAPACITOR
CMPL............... METAL PLASTIC CAPACITOR
CMPP..............
METAL POLYPROPYLENE CAPACITOR
