GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 13 inch / 335.4mmV
System CRT Type Normal
Deflection 90 degree
Magnetic Field BV/BH +0.45G / 0.18G
Color System NTSC
Speaker 1Speaker
Position Front
Size 1.5 x 2.5 Inch
Impedance 8 ohm
Sound Output MAX 1.5 W
10%(Typical) 1.0 W
G-2 VCR System VHS
Player / Recorder
System Video System NTSC
Hi-Fi STEREO No
NTSC PB -
Deck DECK OVD-7
Loading System Front
Motor 3
Heads Video Head 2 Head
FM Audio Head No
Audio /Control Mono/Yes
Erase(Full Track Erase) Yes
Tape Rec PAL -
Speed NTSC SP/SLP
Play PAL -
NTSC SP/LP/SLP
Fast Forward / Rewind Time (Approx.) at 25oC FF:4'50"/REW:2'30"
with Cassette at T-120
Forward/Reverse NTSC or PAL-M SP/LP/SLP=3x,5x/7x,9x/9x,15x
Picture Search -
Frame Advance Slow -
Slow Speed Variable Slow -
G-3 Tuning Broadcasting System US Sysytem M
System Tuner and System 1Tuner
Receive CH Destination US (w/CATV)
Tuning System F-Synth
Input Impedance VHF/UHF 75 ohm
CH Coverage
2~69, 4A,A-5~A-1, A~I,
J~W
,
W+1~W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.5MHz
Preset CH
No
Stereo/Dual TV Sound
No
Tuner Sound Muting Yes
G-4 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level 1 V p-p/75 ohm
S/N Ratio (Weighted) 50 dB
Horizontal Resolution at SP Mode 220Lines
Audio Signal Input Level -8dBm/50Kohm
Output Level -8dBm/1Kohm
S/N Ratio at SP (Weighted) 38dB
Harmonic Distortion at SP (1KHz) Typical
1.5 %
Frequency Response at SP 100Hz ~10kHz
at LP -
at SLP 100Hz ~4kHz
Hi-Fi Audio Signal Dynamic Range : More than -
Wow And Flutter : Less than -
Channel Separation : More than -
Harmonic Distortion : Less than -
G-5 Power Power Source AC 120V 60Hz
DC 12V
Power Consumption at AC 65 W at 120V 60Hz
at DC 54W at 12V
Stand by (at AC) 4 W at 120V 60 Hz
Per Year -
Protector Power Fuse Yes
Dew Sensor Yes
G-6 Regulation Safety UL
Radiation FCC
X-Radiation DHHS
G-7 Temperature Operation
+
5
o
C
~ +4
0
o
C
Storage
-2
0
o
C
~ +
60
o
C
G-8 Operating Humidity Less then 80% RH
G-9 On Screen Menu Yes
Display Menu Type Character
A3-1
