Memorex MVT2137 User Manual

CHASSIS REPLACEMENT PARTS LIST
REF. NO. PART NO. DESCRIPTION REF. NO. PART NO. DESCRIPTION
300 A5A317C420K DECK ASSY A5A317C420K 501 8107226804 SCREW,TAP TITE(S) BIND 2.6x8
502 810A123504 SEMS A M2.3x5.0
301 85OA400234 PINCH ROLLER BLOCK 503 8107226404 SCREW,TAP TITE(S) BIND 2.6x4
302 85OA500026 AHC ASS'Y 504 8102120604 SCREW,PAN M2x6
303 85OP200290 BELT,CAPSTAN (S) 505 8109126604 SCREW,TAP TITE(B) PAN 2.6x6
304 85OP600581 WORM 506 810A130404 SCREW/WASHER(A) M3x4
305 85OP500083 BASE,AC HEAD 507 810A126504 SCREW/WASHER(A) M2.6x5
306 85OP800324 SPRING,AC HEAD 508 82Q264713N POLYSLIDER WASHER 2.6x4.7xT0.13
307 85OA000459 MAIN CHASSIS ASS'Y 509 82P184505N POLYSLIDER WASHER(CUT) 1.8x4.5xT0.5
308 85OA200089 CLUTCH ASS'Y
309 85OA200090 ARM IDLER ASS'Y 510 83ETW30000 E-RING 3.0
511 8107226604 SCREW,TAP TITE(S) BIND 2.6x6
310 85OA300065 LOADING ARM S UNIT
311 85OA300066 LOADING ARM T UNIT CD1501 122H071603 CORD JUMPER SMCD-7X151
312 85OA400223 INCLINED BASE T UINT 3S CD1502 122Y021902 CORD JUMPER 2Y021902
313 85OA400232 P5 ARM ASS'Y 2 D1100 DAK0000170 DEW SENSORCW/AL,PLATE HDP-05-26
314 85OA400235 TENSION ARM ASS'Y 2 H5001 1523D91034 HEAD (AUDIO CONTROL) HVMXA1072A
315 85OA400231 INCLINED BASE S UNIT H5002 1543D02013 HEAD (FULL ERASE) HVFHP0032A
316 85OP800358 SPRING,LOCKER
!
M101 1596P98001 MOTOR (LOADING) MXN13FB12K3
317 85OP900736 CASS,HOLDER
!
M2001 1510S98036 CAPSTAN DD UNIT F2QVB08
318 85OP900748 CASS,SIDE L
!
M2003 1589S11014 MICRO MOTOR I2OAL03
319 85OP900749 CASS,SIDE R
!
UN4001 A5A305A500 CYLINDER UNIT ASS'Y A5A305A500
320 85OP900739 LOCKER,R
321 85OA900228 LINK UNIT
322 85OP000496 POST,CASS GUIDE
323 85OP200316 REEL,S (S)
324 85OP200317 REEL,T (S)
325 85OP200308 GEAR,IDLER
326 85OP200311 GEAR,CLUTCH
327 85OP200312 GEAR,COUPLING
328 85OP200313 LEVER,CLUTCH
329 85OP300194 GEAR,MAIN LOADING
330 85OP400490 LEVER,TENSION
331 85OP400492 HOLDER,TENSION
332 85OP400520 CAP.P4
333 85OP400539 BAND,TENSION
334 85OP400533 CONNECT,TENSION
335 85OP600573 ARM,BRAKE T
336 85OP600583 BAND,BRAKE T
337 85OP600577 CAM,PINCH ROLLER
338 85OP600578 CAM,MAIN
339 85OP600579 ROD,MAIN
340 85OP600582 GEAR,JOINT
341 85OP800322 SPRING,TENSION
342 85OP800360 SPRING,BRAKE T
343 85OP800355 SPRING,COUPLING
344 85OP800356 SPRING,RING
345 85OP900750 LEVER,LINK 2
346 85OP900744 LEVER,FLAP
347 85OP900745 CASS,OPENER
348 85OP900746 BRACKET,TOP 3V
349 85OP700039 COVER,BOT
J2-1
