The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
H-1
WAVEFORMS
Y/C/AUDIO/CCD/HEAD AMP MICON
10 PB
1.0V 10ms/div
9 POWER ON
1.0V 20µs/div
2 POWER ON
100mV 0.1µs/div
1PB
0.5V 20µs/div
8 POWER ON
0.5V 10ms/div
5 REC
10.0V 5us/div
3 PB
10mV 20us/div
4 PB
0.5V 1ms/div
DEFLECTION
17 0.5V 5ms/div
7 PB
1.0V 5ms/div
12 POWER ON
1.0V 10µs/div
11 PB
0.5V 0.5ms/div
18 200mV 20µs/div
19 10.0V 5ms/div
CRT
20 50.0V 20µs/div
