The following waveforms were measured at the point of the corresponding
balloon number in the schematic diagram.
NOTE:
H-2
WAVEFORMS
22 50.0V 20µs/div
21 50.0V 20µs/div
16 200mV 20µs/div
CHROMA/IF
15 100mV 20µs/div
