A. Insert the Left Handrail(#16L) into the Left Rocker(#25L), align the hole of bolts.
B. Use the Multi-function Cross Wrench(#A) to tighten the Left Handrail(#16L) with the Square
Neck Bolt(#24),Flat Washer(#6) and Nylon Nut(#39).
C. Insert the Right Handrail(#16R) into the Right Rocker(#25R), align the hole of bolts.
D. Use the Multi-function Cross Wrench(#A) to tighten the Right Handrail(#16R) with the Square
Neck Bolt(#24), Flat Washer(#6) and Nylon Nut(#39).
Step 4: Install the Handrails
09
Assembly Instructions
