2. Fasten the rigging grommet and rigging adapter with two M6 x 30 screws
and one M6 x 50 screw. Tighten the screws to the specified torque.
3. Secure the wiring, hoses, and cables together with a cable tie.
NOTICE
Inspect the position of the hose clamp located on the fuel hose to ensure
that it will not chafe or cut into the adjacent wiring harnesses.
