10. Technical Data
THE COOKER IS CATEGORY: CatII
2H3+
.
It is supplied set for group H natural gas. A conversion kit from NG to LP is packed with the cooker.
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening.
COUNTRY OF DESTINATION: GB, IE.
Connections
Gas (Rp ½ at rear right-hand side) Electric
Natural gas 20 mbar 230/400 V 50 Hz
Butane 29 mbar
Propane 37 mbar
See the appliance badge for test pressures.
Dimensions
Height (to top of side panel) minimum 920 mm maximum 945 mm
Height (to top of fascia) minimum 920 mm maximum 945 mm
Overall width 1190 mm
Overall depth 638 mm to front of fascia; 700 mm over handles
Minimum height above hotplate 800 mm
Refer to 'Positioning the Cooker'.
Ratings
Hotplate Bypass Screw*
Natural Gas 20 mb L.P. Gas
Injector Injector
Wok burner 57 5.0 kW 165 5.0 kW (357 g/h) 107
Large burner 40 3.0 kW 120 3.0 kW (214 g/h) 82
Small burner 32 1.7 kW 95 1.7 kW (121 g/h) 64
* The valves in this cooker are fitted with adjustable bypass screws. The cooker is supplied with the bypass screws set for
Natural gas. For LPG conversion the bypass screws must be screwed all the way down.
Oven Efficiency
Ovens
Left-hand Oven Right-hand Oven
Multi-function Forced Air Convection
Maximum power output 2.5 kW 2.5 kW
Energy eciency class on a scale of A (more ecient) to G (less ecient) A A
Energy consumption based on standard load 0.95 kWh 0.90 kWh
Usable volume (litres) 78 78
Size Large Large
Time to cook standard load 41 minutes 38 minutes
Surface area of the grid 1400 cm
2
1400 cm
2
Grill 2.3 kW
Maximum total electrical load at 230 V (approximate total including oven lights, oven fan, etc.): 7.4 kW.
ArtNo.105-0008 - Technical data - 90 induction - Elan
