MAINTENANCE
117
5. Remove the spark plugs to inspect. Replace spark plug if
electrode is worn, threads of seal area are corroded, or the
insulator is rough, cracked, broken, blistered or fouled.
6. Set the spark plug gap to specifications.
ob00680
Spark Plug
Spark Plug Gap 0.8 mm (0.0315 in.)
7. Saltwater use - Apply a thin coating of Anti-Seize Compound
only on threads of spark plugs.
Tube Ref No. Description Where Used Part No.
81
Anti-Seize
Compound
Spark plug threads 92-881091K1
8. Before installing spark plugs, clean off any dirt on the spark
plug seats. Install plugs finger tight, and then tighten 1/4 turn
or torque to specifications.
Description Nm lb. in. lb. ft.
Spark plug 27 20
9. Push pencil coils into place over the spark plugs using a
twisting motion.
10.Secure coils with retained bolts. Torque to specifications.
