ENGINE INSTALLATION
111
3. To prevent a loss of the outboard, secure the outboard to the
transom with the two transom bracket clamp screws and two
mounting bolts. Drill two 7.9 mm (5/16 in.) holes through the
transom bracket mounting holes. Fasten with two bolts, flat
washers, and locknuts. Use a marine waterproofing sealer in
the holes and around the bolts to make the installation water
tight. Tighten the bolts to the specified torque.
Manual tilt models
a - Bolt (2)
b - Washer (2)
c - Locknut (2)
d - Transom bracket clamp screw (2)
Description Nm lb. in. lb. ft.
Transom bracket mounting bolts 13.5 10
