MAINTENANCE
86
7. Install the front thrust hub onto the shaft so that the larger
diameter end is facing the propeller.
8. Install the propeller, rear thrust washer, and propeller nut onto
the shaft.
9. Place a block of wood between the gearcase and the propeller
to prevent rotation and tighten the propeller nut to the specified
torque.
NOTE: If the propeller nut doesn't align with the propeller shaft
hole after tightening, tighten the nut further to align with the hole.
10.Align the propeller nut with the propeller shaft hole. Insert a
new cotter pin in the hole and bend the ends.
a - Cotter pin
b - Propeller nut
c - Rear thrust washer
d - Front thrust hub ‑ Larger diameter end towards
propeller
Description Nm lb. in. lb. ft.
Propeller nut 12 106 8
Fuse Replacement ‑ Electric Start Models
IMPORTANT: Always carry spare 20 amp fuses.
