Installing Outboard
BOAT TRANSOM HEIGHT REQUIREMENT
1. Measure the transom height of your boat. The anti‑ventilation plate should
be 25 ‑ 50 mm (1 ‑ 2 in.) below the bottom of the boat.
a - Anti‑ventilation plate
INSTALLING OUTBOARD ON TRANSOM
1. Place outboard on center line of transom.
27005
2. Tighten transom clamp handles.
28377
a
28376
INSTALLATION
22 eng
