WIRING DIAGRAMS
Page 2D-62 90-883728 JULY 2001
CALIBRATION
SPEED UNITS
KN - KPH - MPH
[DOWN]
[UP]
[SAVE]
Display boat speed in KN (knots), KPH (kilometers per hour),
MPH (miles per hour). Press + or – to select setting. Press
MODE to save.
CALIBRATION
EXTERNAL SENSORS
[EDIT]
[SKIP]
CALIBRATION
SPEEDO SENSOR ? YES/NO
EXTERNAL SENSORS
[DOWN]
[UP]
[SAVE]
CALIBRATION
PADDLE WHEEL SENSOR ? YES/NO
EXTERNAL SENSORS
[DOWN]
[UP]
[SAVE]
CALIBRATION
WATER TEMP SENSOR ? YES/NO
EXTERNAL SENSORS
[DOWN]
[UP]
[SAVE]
Press MODE to skip to the next display. Press + (edit) if your
adding or deleting any external sensor to the SmartCraft Sys-
tem.
Editing External Sensors
Add Yes or No for each sensor
No = not used Yes = in use
Press + or – for correct setting
Press MODE to save and advance to next sensor
[DOWN]
[UP]
[SAVE]
CALIBRATION
FUEL TANK CAPACITY
CAPACITY = XX.XX
Add the capacity of the fuel tank. Press + or – to select.
Press MODE to save.
CALIBRATION
[EDIT]
[SKIP]
CALIBRATING
FUEL TANK CALIBRATION
EMPTY TANK
THEN PRESS PLUS (+) BUTTON
[DFLT]
[SAVE]
[SKIP]
CALIBRATING 1/4 VALUE
[DFLT]
[SAVE]
[SKIP]
THEN PRESS PLUS (+) BUTTON
FILL TO X.X G.
CALIBRATING 1/2 VALUE
[DFLT]
[SAVE]
[SKIP]
THEN PRESS PLUS (+) BUTTON
FILL TO X.X G.
CALIBRATING 3/4 VALUE
[DFLT]
[SAVE]
[SKIP]
THEN PRESS PLUS (+) BUTTON
FILL TO X.X G.
CALIBRATING FULL
[DFLT]
[SAVE]
[SKIP]
THEN PRESS PLUS (+) BUTTON
FILL TANK TO FULL
This calibration sets the fuel level of the tank.
NOTE: If the fuel tank is not calibrated, fuel range cannot be
displayed
Press MODE to skip to the next display. Press + (edit) to
calibrate the fuel tank.
Pressing DFLT (default) during edit will return to original value
setting
Calibrate the fuel tank as follows:
1. Empty the fuel tank, Press + to save
2. Fill tank to 1/4 full, Press + to save.
3. Fill tank to 1/2 full, Press + to save
4. Fill tank to 3/4 full, Press + to save.
5. Fill tank to full, Press + to save.
The fuel tank is now calibrated
