POWERHEAD
90-883728 JULY 2001 Page 4A-23
12. Remove water hose from fitting on exhaust adaptor plate.
58069
a
b
a-Water Hose
b-Fitting
13. Remove 10 nuts and 10 washers (5 each side) from powerhead base.
a
a
a
a
a
51846
a-Nuts and Washers (5 each side)
14. Remove plastic cap from center of flywheel and install Lifting Eye 91-90455 into flywheel
at least 5 full turns. Using a hoist, lift powerhead assembly from driveshaft housing.
58890
a
a-Lifting Eye 91-90455
To Next Page
