Mercury 200XRI User Manual

SPECIFICATIONS
Page 1A-2 90-883728 JULY 2001
MID
SECTION
Power Trim (Total Tilt Range)
Power Trim (Tilt Range)
Maximum Allowable Leak down in 24
hrs.
Tilt Pin Adjustment Positions
Steering Pivot Range
Allowable Transom Thickness
75°
20°
1 in. (25.4 mm)
5
60°
2-3/8 in. (6.03 cm) Maximum
FUEL
SYSTEM
Fuel
Recommended Gasoline
Recommended Oil
Gasoline/Oil Ratio
Gasoline w/Oil Injection
Unleaded 87 Octane Minimum
Quicksilver or Mercury Precision Lubri-
cants NMMA/BIA Certified TC-W3
2 Cycle Outboard Oil
50:1 (25:1 Break-In) ECM Controlled –
no premix
STARTING
SYSTEM
Electric Start – All Models
Centrifugal Bendix
Starter Draw (Under Load)
Starter Load (No Load)
Minimum Brush Length
Solenoid Driven Bendix
Starter Draw (Under Load)
Starter Load (No Load)
Minimum Brush Length
Battery Rating
165 Amperes
30 Amperes
0.25 in. (25.4 mm)
175 Amperes
60 Amperes
0.25 in. (25.4 mm)
Min. 630 Marine Cranking Amps
(MCA) or 490 Cold Cranking Amps
(CCA)
IGNITION
SYSTEM
Type
Spark Plug Type
Spark Plug Gap
Firing Order
Idle Timing
Maximum Timing
Throttle Position Sensor
Digital Inductive
NGK BPZ8HS-10
0.040 in. (1.0 mm)
1-2-3-4-5-6
Not Adjustable; Controlled by ECM
Not Adjustable; Controlled by ECM
Not Adjustable; Controlled by ECM
CHARGING
SYSTEM
Alternator Output (Regulated)
Brush Length
Voltage Output
Regulator Current Draw
42 – 48 Amperes @ 2000 rpm @ Bat-
tery
52 – 60 Amperes @ 2000 rpm @ Al-
ternator
Std. Exposed Length: 0.413 in. (10.5
mm)
Min. Exposed Length: 0.059 in. (1.5
mm)
13.5 to 15.1 Volts
0.15 mA (Ign, Switch Off)
30.0 mA (Ign. Switch On)
