SPECIFICATIONS
90-883728 JULY 2001 Page 1A-3
GEAR
HOUSING
Gear Ratio
– Models 150XRI
– Models 175XRI/200XRI
Gear Ratio – High Altitude
– Models 150XRI/175XRI/200XRI
Gearcase Capacity
– 1.87:1/2.00:1
Pinion Height
– All Models
Forward Gear Backlash
– 1.87:1 Ratio
– 2.00:1 Ratio
Water Pressure @ rpm
2.00:1 (14/28 teeth)
1.87:1 (15/28 teeth)
2.00:1 (14/28 teeth)
22.5 fl oz (665.4 ml)
0.025 in. (0.64 mm)
0.018 in. – 0.027 in.
(0.460 mm – 0.686 mm)
0.015 in. – 0.022 in.
(0.381 mm – 0.558 mm)
12 psi Minimum @ 5500 rpm
OIL
INJECTION
Recommended Oil
Oil Tank Capacity
Approx. Time
– Model 150XRI/175XRI/200XRI
Reserve Capacity/Approx. Time
Oil Pump Output
– Model 150XRI/175XRI/200XRI
Quicksilver or Mercury Precision Lubri-
cants NMMA/BIA Certified TC-W3
2 Cycle Outboard Oil
3 gal. (11.4 Liter)
6.6 hrs. Approx.
0.74 qt. (0.70 Liter) 20 – 25 min.
26cc during auto prime time period
FUEL
INJECTION
Idle RPM
– All Models
Wide Open Throttle (WOT) RPM
– Model 150XRI/175XRI/200XRI
Float Adjustment (Vapor Separator)
Float Level
Injectors
– All Models (Quantity)
– Injectors are Crank Angle
Driven by ECM
– #1 Cylinder
– #2 Cylinder
– #3 Cylinder
– #4 Cylinder
– #5 Cylinder
– #6 Cylinder
Line Pressure @ Injectors
Injector Resistance
Electric Fuel Pump Resistance
Electric Fuel Pump Amperage Draw
625 ± 50
5250 – 5750
Preset @ Factory
6
RED + BRN Leads
RED + WHT Leads
RED + ORG Leads
RED + YEL Leads
RED + LT BLUE Leads
RED + PUR Leads
41 psi – 45 psi (283 kPa – 310 kPa)
12.3 ohms ± 0.5 ohms
0.7 ± 0.3 ohms
4 amperes ± 0.5 amperes
