Mercury 225 VERADO User Manual

MAINTENANCE
115
Propeller Replacement
1. Shift outboard to neutral position.
2. Straighten the bent tabs on the propeller nut retainer.
ob00376
3. Place a block of wood between gearcase and propeller to hold
propeller and remove propeller nut.
ob01672
4. Pull propeller straight off shaft. If propeller is seized to the shaft
and cannot be removed, have the propeller removed by an
authorized dealer.
5. To aid in future removal of the propeller, liberally coat the
propeller shaft splines with one of the following Mercury/
Quicksilver products:
Tube Ref No. Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft
splines
92-802867A1
95
2-4-C Marine
Lubricant with Teflon
Propeller shaft
splines
92-802859A1

Mercury 225 VERADO Specifications

General

Horsepower	225 HP
Full Throttle RPM Range	5800-6400 RPM
Steering	Electro-hydraulic power steering
Dry Weight	635 lbs / 288 kg
Cylinders	6
Gear Ratio	1.85:1
Alternator Output	70 amp (882 watt)
Shaft Length	20", 25"
Starting System	Electric
Warranty	3 years
Fuel Induction System	Electronic Fuel Injection (EFI)
