Mercury 225 User Manual

MAINTENANCE
41
a
b
ob01025
a - Trim tab anode b - Transom bracket anode
Four anodes are installed in the engine. Remove anodes at locations shown. Install each anode with rubber seal
and cover. Torque the anode bolt, than cover retaining bolts to specifications.
a
b
e
ob01026
c
d
a - Anode bolt
b - Cover retaining bolt
c - Cover
d - Anode
e - Rubber seal
Description Nm lb. in. lb. ft.
Anode bolt 8 70
Anode retaining bolts 17 150

Mercury 225 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Horsepower	225 HP
Steering	Hydraulic Steering
Shaft Length	20"
Starting	Electric Start
Cylinders	V6
