The steering link rod parts are available and assembled as illustrated below.
Spacers may or may not be required depending on cable brands.
a - Grease
b - Spacer (optional)
c - Bolt
d - Washer B
e - Rubber cushion
f - Spring
g - Spacer
h - Collar
i - Locknut
j - Rod
k - Washer A
l - Seal ring
Battery Installation
MOUNTING BATTERY
Follow the battery manufacturer's instructions carefully. Mount battery securely
to the hull in a place free from splashing water.
NOTE: Electric starting outboards must have the battery cables connected to a
battery whenever the engine is running, even if started manually, as damage to
the charging system could result.
