OUTBOARD INSTALLATION
126 eng
c. Place a mark on the shift cable against the cable end
guide.
a - Reverse position mark
3. Mark the center on the shift cable midway between the
forward and reverse marks.
a - Center mark
4. Align the cable end guide against this center mark when
installing the cable to the engine.
5. Position the remote control and outboard into neutral
position.
6. Slide the anchor pin forward until resistance is felt, then
slide the anchor pin toward the rear until resistance is felt.
7. Center the anchor pin between these resistance points.
a - Anchor pin
