Mercury 275 VERADO Installation Manual

200/225/250/275 VERADO 4-STROKE
90-10238051 Page 7 / 51
2. Place masking tape directly onto the boat where the mounting holes will be drilled to
help keep the fiberglass from chipping.
3973
3. Using the drill guide holes on the transom drilling fixture, drill four 13 mm (17/32 in.)
holes perpendicular to and through the transom.
Lifting Outboard
1. Remove top cowl and engine flywheel cover.
2. Install lifting ring/flywheel puller to flywheel. Tighten bolts securely.
3. Lift engine using engine lift with a minimum capacity of 450kg (1000 lb.).
4. Avoid interference by placing the lower mounting bolts into the lower mounting slots
before placing outboard against the transom.

Mercury 275 VERADO Specifications

General

Engine Type	4-Stroke
Displacement	2.6 L
Horsepower	275 HP
Full Throttle RPM Range	5800-6400 RPM
Steering	Electro-hydraulic power steering
Shaft Length	25"
Dry Weight	635 lbs
Fuel Type	87 Octane
Starting System	Electric Start
Alternator Amp	70 Amp
