Section 3 - Specifications
Page 32 90-8M0113856 eng DECEMBER 2015
Use the following information for selecting the type of oil according to the order of preference.
Mercury/Quicksilver 25W-40 Synthetic Blend, NMMA FC-W Catalyst Compatible rated 4-cycle oil
Other recognized brands of NMMA FC-W Catalyst Compatible rated 4-cycle oil
SAE 20W
SAE30W
SAE40W
AIR TEMPERATURE
ORDER OF PREFERENCE
(32° F)
0° C
(50° F)
10° C
Mercury/Quicksilver 25W-40 Mineral NMMA FC-W Catalyst Compatible rated 4-cycle oil
53574
Other recognized brands of NMMA FC-W rated 4-cycle oil
Fluid Specifications
Sterndrives
NOTE: Oil capacity includes the drive lube monitor.
Model
Capacity Fluid Type
Alpha One 1892 mL (64 oz) High Performance Gear Lubricant
Engine
IMPORTANT: All capacities are approximate fluid measures.
3.0 TKS
Capacity Fluid Type
Engine oil (with filter) 3.8 L (4 US qt)
Mercury/Quicksilver 25W‑40 Synthetic Blend Engine Oil, NMMA FC‑W Catalyst
Compatible rated
Seawater cooling system 9 L (8.5 US qt) Propylene glycol and purified water
Closed cooling system 9 L (8.5 US qt)
Mercury Extended Life Coolant Antifreeze or extended life ethylene glycol 5/100
antifreeze mixed 50/50 with purified water
Specifications—3.0 TKS
Engine Specifications—3.0 TKS
NOTE: Performance specifications are obtained and corrected in accordance with SAE J1228/ISO 8665 Crankshaft Power.
All measurements are taken with the engine at normal operating temperature.
RPM range is measured using an accurate service tachometer with the engine at normal operating temperatures.
Oil pressure must be checked with the engine at normal operating temperature.
NOTE: Oil pressure specifications are for reference and may vary.
Propshaft power
101 kW (135 hp)
Displacement
3.0 L (181 cid)
Alternator amperage
Hot 72 A
Cold 65 A
RPM
WOT 4400–4800
Rev limiter 4950
Idle in neutral 700
