Section 4 - Maintenance
Page 44 90-8M0113856 eng DECEMBER 2015
Description Specification
Crankshaft position sensor air gap 0.64–1.02 mm (0.024–0.040 in.)
7. Tighten the two spacer block bolts. If necessary, you can loosen the crankshaft position sensor bolts to move the sensor
into position. Tighten all bolts to the specified torque.
Description Nm lb‑in. lb‑ft
Spacer block bolts 68 – 50
Crankshaft position sensor bolts 2 17.7 –
8. Install power steering belt, if equipped. Adjust the tension of both drive belts.
Description
Deflection 6 mm (0.25 in.)
Replacing Belts on Side Mount Models
Power Steering Pump Drive Belt
1. Loosen the power steering pump attaching bolts and mounting bolts.
2. Pivot the power steering pump toward the engine until you can remove the belt.
3. Install the new drive belt. Adjust the tension to the following specification.
Description
Deflection 6 mm (0.25 in.)
Alternator Belt
1. Remove the power steering pump drive belt, if equipped.
2. Loosen the alternator.
3. Remove and replace the alternator belt.
4. Install the power steering belt, if equipped. Move the power steering brace to its original position and adjust the tension of
both drive belts.
Description
Deflection 6 mm (0.25 in.)
Maintenance Schedules—3.0 TKS
Routine Maintenance
NOTE: Only perform maintenance that applies to your particular power package.
New sterndrive installations may require as much as 470 mL (16 fl oz) of gear lube added to the monitor bottle during the
break‑in period (20 hours of running time). It is important to monitor and maintain the gear lube level during the break‑in period.
During the initial drive installation, air may be trapped in the top of the driveshaft housing. This void is filled from the gear lube
monitor during the sterndrive break‑in period. As the air is purged from the sterndrive through the monitor bottle, the lube level
in the bottle will drop.
Task Interval
Maintenance to Be Performed
Each day start
• Check the engine oil level. (You can extend this interval based on experience with the
product.)
• Check the sterndrive gear lube level.
• Check the trim pump oil level.
• Check the power‑assisted steering pump or the compact hydraulic steering fluid level,
depending on the steering system of your model.
Each day end
• If operating in saltwater, brackish water, or polluted water, flush the seawater section of the
cooling system after each use.
