Section 5 - Storage
90-8M0113856 eng DECEMBER 2015 Page 79
4. Remove and lower the hose connecting the water inlet to the power steering cooler, or the water inlet to the heat
exchanger.
a - Power steering cooler
b - Water inlet to heat exchanger hose
5. Ensure that the speedometer pitot hole, gear housing water vent and drain holes, and trim tab cavity vent and drain holes
are open and unobstructed.
a - Gear housing vent holes
b - Trim tab cavity drain holes
c - Gear housing drain hole
d - Speedometer pitot hole
a
c
d
b
7329
