Mercury 300XS OptiMax User Manual

STORAGE
88
2. Remove the drain hose from the aft hose fitting (right side of
the chamber). Hold the unattached end of the hose over a
suitable container.
ob01352
a
b
c
a - Filter drain screw
b - Drain hose
c - Aft hose fitting
3. Loosen the filter drain screw (left side of the chamber) and
allow the contents to drain.
NOTE: If little or no liquid drains from the hose, loosen the red
filter to vent the chamber.
4. Tighten drain screw and reattach the hose.

Mercury 300XS OptiMax Specifications

General

Engine Type	2-Stroke
Horsepower	300 HP
Alternator Output	60 amp / 756 watt
Gear Ratio	1.75:1
Starting System	Electric
Fuel System	2-Stage Direct Fuel Injection (DFI)
Weight	505 lbs / 229 kg
Cylinders	6
Steering	Hydraulic
Shaft Length	25"
