Mercury 45 Operator's Manual

GENERAL INFORMATION
18
Models 40 50 60
Recommended Oil Refer to Fuel & Oil
Gearcase Lubricant
Capacity
83mm (3‑1/4 in.) Diameter
Gearcase
340 ml (11.5 fl. oz.)
108mm (4‑1/4 in.) Diameter
Gearcase
710 ml (24.0 fl. oz.)
Engine Oil Capacity 3.0 Liter (3 Quarts)
Battery Rating
Operation Above 0 °C
(32 °F)
465 Marine Cranking Amps (MCA) or 350 Cold Cranking
AMPS (CCA)
Operation Below 0 °C
(32 °F)
1000 Marine Cranking Amps (MCA) or 750 Cold Cranking
AMPS (CCA)
Ampere Hours (Ah) 70 ‑100
Sound at Drivers Ear
(ICOMIA 39‑94)
4‑Stroke 77.4
4‑Stroke with tiller 83.2

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
