Mercury 50 Operator's Manual

FUEL & OIL
26
+20
+40
+60
+80
F° C°
0
+100
7
+4
+16
+27
18
+38
a
b
11583
Recommended SAE Viscosity for Engine Oil
a - NMMA FC‑ W certified 10W‑30 outboard oil
may be used at temperatures below 4 °C
(40 °F)
b - NMMA FC‑W certified synthetic blend
25W‑40 outboard oil may be used in all
temperatures.
Checking And Adding Engine Oil
IMPORTANT: Do not overfill. Be sure that the outboard is upright (not tilted) when checking oil.
1. Turn the engine off. Have the outboard in a level operating position. Remove the top cowl.
2. Flip the handle up and pull out the dipstick. Wipe it with a clean rag or towel and push it back in all the way.
3. Pull the dipstick back out again and observe the oil level. If the oil level is low, remove the oil filler cap and
fill to (but not over) the upper oil level with the recommended oil.
ob01456
IMPORTANT: Inspect oil for signs of contamination. Oil contaminated with water will have a milky color to it; oil
contaminated with fuel will have a strong fuel smell. If contaminated oil is noticed, have the engine checked by
your dealer.

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
