OPERATION
61
7. Move throttle grip to start position.
.
27239
8. Models without power trim ‑ Position the tilt lock lever to the
lock/run position.
a
b
26802
a - Tilt position b - Lock/run position
!
WARNING
Rapid acceleration can result in serious injury or death from
being thrown within or out of the boat. Decrease engine speed
before shifting into gear.
9. Manual starting models:
a. If engine is cold, push in the primer bulb rapidly 4 to 6 times.
NOTE: For initial start of a new engine or first start after a
prolonged storage, primer lines may have air in them. In this case,
push in the primer bulb several times until fluid can be felt and
then the normal 4 to 6 times.
3076

Mercury 50 Specifications

General

Horsepower	50 hp
Cylinders	3
Steering	Remote
Starting	Electric
Displacement	995 cc
Fuel Induction System	EFI (Electronic Fuel Injection)
Alternator Output	18 amp
Shaft Length	20" / 508 mm
Dry Weight	112 kg
Engine Type	4-Stroke
