CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–9
Crankshaft
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 CRANKSHAFT
2 1 WASHER
3 1 KEY
4 1 CONNECTING ROD
5 2 BOLT 106 12
6 1 PISTON PIN
7 2 E RING
1 PISTON (STANDARD) (4/5 H.P.)
8
AR PISTON (.05 MM O/S) (4/5 H.P.)
8
1 PISTON (STANDARD) (6 H.P.)
AR PISTON (.05 MM O/S) (6 H.P.)
9
1 PISTON RING-TOP (STANDARD)
9
AR PISTON RING-TOP (.05 MM O/S)
10
1 PISTON RING-SECOND (STANDARD)
10
AR PISTON RING-SECOND (.05 MM O/S)
11
1 OIL RING (STANDARD)
11
AR OIL RING (.05 MM O/S)
AR = As Required
